Gigabyte RTX 5070 Ti EAGLE OC SFF 16GB

CUDA® Cores: 8,960 Units
Memory:
- Size: 16 GB
- Type: GDDR7
- Memory Bus: 256-bit
- Memory Speed: 28 Gbps effective
- Memory Bandwidth: 896 GB/s
Core Clocks:
- Boost Clock (OC Mode): 2542 MHz (Gigabyte's factory overclock)
- Reference Boost Clock: 2452 MHz
- Base Clock: 2295 MHz (NVIDIA reference)
Bus Interface: PCI Express 5.0 x16
Ray Tracing Cores: 4th Generation NVIDIA RT Cores
Tensor Cores: 5th Generation NVIDIA Tensor Cores (for AI and DLSS acceleration, including DLSS 4 with Multi Frame Generation)
AI Performance: 1484 TOPs (Total Operations Per Second)
Video Outputs:
- 3 x DisplayPort 2.1b
- 1 x HDMI 2.1b
- Digital Max Resolution: 7680x4320 (8K)
- Maximum Displays: Up to 4
Cooling System: GIGABYTE WINDFORCE cooling system, typically featuring:
- Triple Hawk fan design (optimized for airflow and static pressure).
- Large copper plate and composite copper heat pipes for efficient heat transfer.
- Server-grade thermal conductive gel for VRAM and MOSFETs.
- 3D Active Fan (fans stop at low loads for silent operation).
- Screen Cooling (extended heatsink for air passthrough).
Power Connectors: 1 x 16-pin (12V-2x6 / 12VHPWR style)
TDP (Total Design Power): 300 W
Recommended PSU: 750W or higher
Card Dimensions (L x W x H): Approximately 304mm x 126mm x 50mm (a 2.5-slot design, meeting SFF specifications).
DirectX Version Support: 12 Ultimate
OpenGL Version Support: 4.6
- Graphene Nano Lubricant for fan longevity.
- Versatile VGA holder included.
