ASUS PRIME GeForce RTX™ 5070 Ti 16GB GDDR7 OC Edition

Graphics Processor: NVIDIA GeForce RTX 5070 Ti (based on Blackwell architecture, likely the GB203 GPU)
CUDA® Cores: 8960
Memory:
- Size: 16 GB
- Type: GDDR7
- Memory Bus: 256-bit
- Memory Speed: 28 Gbps effective
- Memory Bandwidth: 896 GB/s
Core Clocks:
- OC Mode Boost Clock: 2527 MHz
- Default Mode Boost Clock: 2497 MHz
- Base Clock: 2295 MHz
AI Performance: 1432 AI TOPs (Total Operations Per Second)
Bus Interface: PCI Express 5.0 x16
Ray Tracing Cores: 4th Generation NVIDIA RT Cores
Tensor Cores: 5th Generation NVIDIA Tensor Cores (for AI and DLSS acceleration, including DLSS 4 with Multi Frame Generation)
Video Outputs:
- 3 x DisplayPort 2.1b
- 1 x HDMI 2.1b
- Digital Max Resolution: 7680 x 4320 (8K)
- Maximum Displays: 4
Cooling System: ASUS PRIME cooling design, often featuring:
- Axial-tech fans with longer blades for improved airflow and dispersion.
- Dual Ball Fan Bearings for extended lifespan.
- Phase-Change GPU Thermal Pad for optimal heat dissipation.
- A robust heatsink design.
- 0dB Technology for silent operation under light loads.
Power Connectors: 1 x 16-pin (12V-2x6 / 12VHPWR style)
TDP (Total Design Power): 300 W (or slightly lower, some sources list 290W for reference, but OC editions can be higher)
Recommended PSU: 750W or higher
Card Dimensions (L x W x H): Approximately 304 x 126 x 50 mm (a 2.5-slot design, making it more compact than some other models, and often "SFF-Ready").
DirectX Version Support: 12 Ultimate
OpenGL Version Support: 4.6

ASUS PRIME GeForce RTX™ 5070 Ti 16GB GDDR7 OC Edition
